Ventilator Non Power Roof Mounted Air Exhaust Fan

Ventilator Non Power Roof Mounted Air Exhaust Fan

No-power Roof Turbine Ventilator is to make use of the air free convection that natural wind power and the interior outside temperature difference bring about, the effect driving a turbine to rotate making use of centrifugal force and negative pressure thereby discharge the interior stale

Product’s Features:

  1.  No maintenance or operating costs,
  2.  Water and dust proof
  3.  Improves air quality
  4.  Improves productivity.
  5. The structure of the high quality
  6. The precision of the running device,
  7. Green environmental protection ventilation equipment
  8.  Applicability widely. All kinds of industrial factory building contour plate light steel structure roofing, concrete roof can also be installed. And there’s no need to support, installation is convenient. roof air ventilator

Product Description


Roof Ventilation Fan Machine

Functions and Features of Non power roof fan

1,It can absorb the hot air, moisture, dust, foul smell, smoke from residence and from kitchen chimneys of workshops automatically, also it can decrease indoor noise, increase light.

2,It runs automatically all the time and no stop according to natural weather; It doesn't need any power, saving energy and cost.

3, It is installed on the top of buildings or on the wall with good appearance.

4, Simple and convenient installation, No Operational and Maintenance Costs.

5, No roof leaking, 100% waterproof result with raining or snowing weather.

6,Enhances the architectural and aesthetic appearance of buildings.

7, It suits all roof types with slopes from zero to 22.5degree.

8, Precision steel bearings imported from abroad.

9, Improves efficiency of air conditioning. Where ducted air conditioning is installed at home. It will

Roof Ventilation Fan Machine

Advantage:

1- Automatic driving by wind, working 24 hours of a day 2- High sensitivity, the blades drive with slight wind, the difference in temperature also makes the blade driving. 3- Stable rotary, mute sounds so no influence of the workshop 4- Complete senior axis bearing, no lubrication 5- Corrosion resistant, acid proof and alkali proof, long time using 6- Different size according to the size of the workshop, size can be 300~600mm 7- material: color seel, stainless steel 201/304

Model No.
C
B
A
VANES
MATERIAL
100mm
180mm
150mm
100mm
14
SS /COLOR SHEET
150mm
200mm
220mm
150mm
16
SS /COLOR SHEET
200mm
240mm
300mm
200mm
18
SS /COLOR SHEET
300mm
350mm
400mm
300mm
24
SS /COLOR SHEET
400mm
380mm
480mm
400mm
26
SS /COLOR SHEET
500mm
480mm
600mm
500mm
32
SS /COLOR SHEET
600mm
580mm
700mm
600mm
32
SS /COLOR SHEET
680mm
600mm
800mm
680mm
32
SS /COLOR SHEET
800mm
650mm
900mm
800mm
42
SS /COLOR SHEET
880mm
700mm
1000mm
880mm
42
SS /COLOR SHEET

Roof Ventilation Fan Machine Roof Ventilation Fan Machine Roof Ventilation Fan Machine

Blade
Blade:Curved blades are the beat results of scientific caculation and it can strickly ensure that no rainwater intrution.
304 stainless steel material: Selection of fine steel, every detail carefully made, hard appearance, corrosion resistance
No power and no maintenance:There is no need for automatic exhaust of electricity throughout the day, and it can reduce fire and a lot of other unnecessary troubles caused by short circuit of wires or voltage overload.
voice:Noise free and durable There is no noise when the fan is running, and the core of the fan is made of closed bearing, and the blade base is made of stainless steel sheet in one stamping form, which is anti-corrosion, acid and alkali resistance, anti-aging, and has a long service life

Applications

The roof turbine fan have Widely used in these places
Hotels, Garment Shops, Building Material Shops, Manufacturing Plant, Machinery Repair Shops, Food & Beverage Factory, Farms, Restaurant, Home Use, Retail, Food Shop, Printing Shops, Construction works , Energy & Mining, Food & Beverage Shops, Other, Advertising Company and so on.
ventilator non power roof mounted air exhaust fan, roof turbine ventilator roof ball fan, roof ventilator turbine for exhaustfan, warehouse greenhouse roof exhaust ventilation fan
Roof Ventilation Fan Machine Roof Ventilation Fan Machine
BUILDING TYPE SQUARE/ pieces SELECT MODEL BUILDING TYPE Exhaust times/ Hour
STEAM WORKSHOP 20-40m² YC500-YC1000 warehouse 4-8
CHEMICAL ODOR WORKSHOP 30-80m² YC600- YC1000 garage 4-10
DUST WORKSHOP 40-80m² YC500-YC1000 Printing Broad 5-12
BREEDING WORKSHOP 60-100m² YC400-YC1000 Assembly Hall 6-12
JINGROUGH AMARANTH VENTILATION WORKSHOP 50-100m² YC500-YC1000 Chemical workshop 8-14
PUBLIC BUILDINGS AND RESIDENTIAL BUILDINGS 40-100m² YC160-YC1000 High temperature workshop 10-16
OTHER 80-120m² All are available Gymnasium and tennis court 3-10
