500 Ton Maize Steel Silos

Feed silos (also called feed bins, gravity feed bins) are the steel silos with 60° cone bottom which are commonly used to storage small capacity pelleted products and grains

WhatsApp：+8615020642375

Product Description

Feed silos (also called feed bins, gravity feed bins) are the steel silos with 60° cone bottom which are commonly used to storage small capacity pelleted products and grains, allowing them to discharge freely through gravity from the silo into a bag, barrow, conveyor or truck whilst ensuring that the stored products are in the finest qualified condition. All our feed silos are made with corrugated galvanized steel. The feed bin bottom is designed with with 60° cone to let the stored pellets flow out freely without fragmentized. The Galvanization of our silos is Z600g/m2 in accordance with UNE-EN 36130, which make them durable and weatuer resistant. The galvanizing sheet is 275g/m2as standard design, according to some customers special request, 350g/m2and 400g/m2are options for their needs. Feed silos can help you get maximum efficiency when loading and unloading stored products. They are also protect the inside storage away from outside insects and danger. Feed silos can be integrated with automatic feeding systems for a variety of livestock industries.

Advantages：

1). Silo standard ladder which has a guard railing and is safe and reliable;

2). Firm connection and good sealing performance;

3). High-quality plates, for more than 30-year service life

Main Features

1.High quality raw material.
2. Double side dip galvanized with passivation , it can keep 15 years not rust.
3. The overall design is scientific, with overall moulding production process
4. There is a ventilate hole at the top of the silo, timely discharge the heat air and avoid the feed turning mildew.
5. High strength, corrosion resistance, long life, easy installation.

Silo Body Produce Machine

The New Silo Body Produce Machine Can Produce the Silo form 3 T to 1000 T.

1. Totally New Machine;

2. Sufficient Production Capacity;

3. Produce Different Size Silo to Meet

Customers' Need;

Silo Ring Sheets

1. Constructed with Hot-galvanized corrugated

steel plate, Which Can Reduce The Silo

Inside Condensation & Moisture.

2. ZN-Coat thickness≥275 g/m² ;

3. Out ring cover with film which avoid scratch

during transit.

3. Sealing glue is added between the ring

sheets to prevent water entering the silo to

avoid feed mildew.

Silo Inlet Cover & Automatic Opening Control

1.304 SS Top Cover, High Strength, No Rust;

2. With Our Specially Designed Automatic

Elastic Torsion Spring Control Structure,

Customers Can Open and Closed the Top

Cover Easily and Safe.

Air Duct

The Silo Roof Sheet Has An Air Duct, Which Can Balance The Air Pressure

Between Silo Side and Outside, Discharge Various Gases And Heat, Ensure

Feeding Smoothly and Keep the Silo Inside Clean.

Technical Data
Model	Diameter(mm)	Capacity(t)	Capacity(m³）	Silo Height(m)	Layers	Legs
SH-1800-1	1800	2.5	3.9	3418	1	4
SH-1800-2	1800	3.9	6.0	4231	2	4
SH-1800-3	1800	5.3	8.1	5042	3	4
SH-1800-4	1800	6.6	10.2	5853	4	4
SH-1800-5	1800	7.9	12.3	6664	5	4
SH-1800-1(Plus)	1800	2.5	3.9	3820	1	4
SH-1800-2(Plus)	1800	3.9	6.0	4633	2	4
SH-1800-3(Plus)	1800	5.3	8.1	5446	3	4
SH-1800-4(Plus)	1800	6.6	10.2	6256	4	4
SH-2750-2	2750	10.3	15.8	5294	2	6
SH-2750-3	2750	13.4	20.6	6109	3	6
